60W MINI MOVING LED BEAM LIGHT

60W Mini Moving LED Beam Light for Stage & Events UAE

The 60W Mini Moving LED Beam Light is a compact DMX512 moving-head fixture designed for weddings, DJ setups, bars, discos and stage productions. It combines a 60W LED source with 8,130 lux illumination at 1 metre, 540° pan, 270° tilt, seven colours and seven fixed gobos for dynamic beam effects in professional and mobile lighting setups.

Technical Specifications

These figures are taken from the technical specification table of the matching 60W product listing.

Compact 60W Beam for Dynamic Stage Lighting

The 60W Mini Moving LED Beam Light combines beam movement, colour changes and patterned gobo effects in a compact fixture suited to smaller and medium-scale event setups.

Its 8,130 lux output at 1 metre provides a clearly defined beam that works particularly well when combined with haze or fog. The 14.3° beam angle gives the fixture enough spread for dance floors and stages while retaining the directional appearance expected from a moving beam light.

A 540° pan and 270° tilt range allows the head to sweep across stages, ceilings and dance floors instead of lighting only one fixed area. Multiple fixtures can therefore be programmed to create synchronized movements, crossing beams and coordinated chase effects.

7 Colours and 7 Fixed Gobos

The fixture incorporates seven colours plus an open position, allowing operators to move between different colour effects during a show.

It also provides seven fixed gobos plus open, adding projected patterns to the beam. This gives DJs and lighting operators more visual variation than a standard single-beam fixture without requiring a separate effects light.

Colour, gobo, movement and other functions can be integrated into programmed lighting scenes through DMX control.

540° Pan and 270° Tilt Movement

The moving-head design provides:

• 540° horizontal pan

• 270° vertical tilt

• DMX512 programming

• Automatic programs

• Sound-active operation

• Master-slave synchronization

This range of control options makes the fixture suitable for both professional DMX installations and simpler event setups where operators want automatic or music-responsive effects.

DMX512 Control with 9CH / 11CH Modes

For programmed lighting systems, the fixture supports 9-channel and 11-channel DMX modes.

DMX control gives lighting technicians greater control over the fixture's movement, colours, gobos and effects. Multiple units can be addressed individually or programmed as part of a larger lighting sequence with compatible DMX controllers.

For mobile DJs or smaller venues without a dedicated lighting console, Auto and Sound modes provide simpler standalone operation.

Compact Design for Mobile and Permanent Setups

At 175 × 146 × 286 mm, this mini moving head requires considerably less installation and transport space than a full-size moving beam fixture.

The compact format makes it practical for mobile DJs, wedding-production companies, smaller stages and venues where several fixtures need to be installed without occupying excessive truss or floor space.

Best For

• Wedding stages and ballroom lighting

• DJs and mobile entertainment setups

• Bars, lounges and nightclubs

• Dance floors and private parties

• Small and medium stage productions

• Corporate events and entertainment shows

• Event-production and AV rental companies

Compatibility & Setup

The 60W Mini Moving LED Beam Light operates from AC100–240V at 50/60Hz, making its electrical range compatible with UAE mains voltage.

It can be integrated with compatible DMX512 controllers and used alongside LED PAR lights, strobes, lasers, moving washes, fog machines and haze machines to create a complete stage-lighting system. The fixture also supports Master-Slave operation when multiple compatible units are used together.

How Bright Is the 60W Mini Moving Beam Light?

The specified illumination is 8,130 lux at 1 metre.

Actual visible beam intensity at an event will depend on throw distance, ambient lighting and atmospheric effects. Using haze or fog can make the beam path significantly more visible in stage and nightclub environments.

What Is the Beam Angle?

The fixture has a specified 14.3° beam angle.

This provides a focused stage-lighting effect while offering more spread than extremely narrow beam fixtures designed mainly for long-distance aerial effects.

Does It Support DMX512?

Yes. The fixture supports DMX512 with 9CH and 11CH operating modes, allowing it to be incorporated into programmable professional lighting systems.

Can It Run Without a DMX Controller?

Yes. In addition to DMX512, the light supports Auto, Sound and Master-Slave modes.

This allows DJs, smaller venues and event operators to create moving lighting effects without requiring a dedicated DMX console.

Is It Suitable for Weddings and DJ Events?

Yes. Its combination of compact dimensions, moving beam effects, colours, gobos and multiple control modes makes it particularly practical for wedding stages, DJs, parties, bars and disco applications. These uses are also listed for the matching product configuration.

Stage Lighting & Moving Head Lights in the UAE

Stagify supplies professional stage lighting and event-production equipment in Dubai and across the UAE for DJs, event companies, AV installers, venues and equipment-rental businesses.

The 60W Mini Moving LED Beam Light can be combined with moving washes, PAR lights, strobes, lasers and atmospheric effects to build a more complete event-lighting setup.

Contact Stagify for project requirements, multi-unit setups and bulk enquiries.
