LED 3 Heads Moving Head laser Stage Light

LED 3 Heads Moving Head Laser Stage Light – Multi-Direction Laser Control for Events

The LED 3 Heads Moving Head Laser Stage Light combines 18 × 10W RGBW 4-in-1 LEDs with red, green and blue laser effects in a three-head moving fixture. It supports DMX512, sound activation, automatic and master-slave operation, making it suitable for DJ shows, clubs, stages, parties and professional event lighting setups across the UAE.

Technical Specifications

The technical values above are supported by both the current product page and the matching MD-JL3 OEM specification.

Three Lighting Effects in One Fixture

Instead of using separate fixtures for beam, laser and strobe effects, this 3 Heads Moving Head Laser Stage Light combines all three functions into one compact stage-lighting unit.

The main lighting section uses 18 × 10W RGBW 4-in-1 LEDs, giving operators red, green, blue and white output for colourful beam effects. The RGBW LED configuration also allows different colours to be mixed rather than limiting the fixture to fixed single-colour beams.

The integrated laser section adds three separate laser colours:

• 100mW red laser

• 50mW green laser

• 50mW blue laser

The laser output adds sharper visual lines and effects that contrast with the wider LED beams, especially when used together with haze or fog in an appropriate venue.

A programmable strobe operating at 1–20 flashes per second adds another layer for high-energy music cues, DJ sets and dance-floor sequences.

Three-Head Design for Dynamic Stage Effects

The three-head design creates a broader and more animated effect than a conventional single moving-head fixture.

Multiple heads can send light effects in different directions across a stage, dance floor or entertainment space, helping one fixture create a more active visual environment.

This makes the unit particularly useful where the goal is not conventional stage illumination, but fast-moving effect lighting for music-driven events.

For DJs and mobile production companies, the combination can also reduce the number of separate effect fixtures needed for smaller installations.

RGBW 18 × 10W LED System

The fixture contains 18 individual 10W RGBW 4-in-1 LED sources.

RGBW technology integrates red, green, blue and white within each LED package. Compared with basic RGB fixtures, the dedicated white component provides an additional output option and expands the range of colours available during programmed shows.

The 0–100% linear dimming function gives DMX operators control over intensity rather than restricting the fixture to simple on/off operation.

This is useful when programming transitions between ambient sequences, moving effects and faster show moments.

RGB Laser Effects

The integrated laser system combines:

• Red: 100mW

• Green: 50mW

• Blue: 50mW

These coloured lasers can add defined aerial effects alongside the RGBW LED beams.

Laser visibility is typically enhanced when suitable atmospheric effects are present, making the fixture a useful pairing with compatible haze or fog machines for controlled professional environments.

Because this is a laser-effect fixture, positioning is important. Lasers should never be aimed into audience areas, and use at public events in the UAE may be subject to venue or relevant authority requirements.

DMX512 and Standalone Control

The fixture supports four operating methods:

• DMX512

• Sound activated

• Automatic

• Master-Slave

The matching OEM configuration specifies 11 DMX channels.

DMX512 is the preferred option for professional event setups because the fixture can be incorporated into programmed lighting scenes alongside other stage equipment.

Sound mode provides a simpler solution for DJs, parties and smaller events where effects need to respond to music without a dedicated lighting operator.

Automatic mode runs built-in sequences independently, while master-slave operation allows compatible fixtures to operate together.

Strobe and Linear Dimming Control

The electronic strobe can run from 1 to 20 flashes per second, providing anything from slower pulse effects to rapid high-energy sequences.

The fixture also supports 0–100% linear dimming, allowing brightness to be adjusted progressively through its control system.

Combining dimming, strobe, RGBW LEDs and lasers gives lighting programmers several effect layers from a single unit.

Best For

The LED 3 Heads Moving Head Laser Stage Light is suited to:

• DJ performances

• Nightclubs and lounges

• Wedding entertainment

• Dance floors

• Private parties

• Concert stages

• Live music events

• Bars and entertainment venues

• Corporate entertainment

• Mobile DJ systems

• Event-production companies

• Stage and show lighting setups

Its effect-focused design makes it particularly useful where movement, colour, laser and strobe effects are more important than general-purpose stage wash illumination.

What's Included & Compatibility

The main package includes the 3 Heads Moving Head Laser Stage Light.

It can be incorporated into lighting systems using:

• DMX512 lighting controllers

• Compatible DMX cables

• Stage truss systems

• Lighting stands with suitable mounting hardware

• Fog machines

• Haze machines

• LED PAR lights

• Beam moving heads

• Strobe lights

• Additional DMX-compatible effects

The documented packing size is 31 × 22 × 40 cm.

Exact mounting hardware and supplied power-plug configuration should be checked against Stagify stock before publication.

Does This Moving Head Have Both LED and Laser Effects?

Yes. It combines 18 × 10W RGBW LEDs with red, green and blue lasers, plus an electronic strobe effect.

This allows one fixture to create beam, laser and strobe sequences.

What Are the Laser Outputs?

The published laser specifications are 100mW red, 50mW green and 50mW blue.

These outputs should be treated as professional laser effects and used with appropriate positioning and operating procedures.

Can It Be Controlled With DMX512?

Yes. The fixture supports DMX512 control, and the matching MD-JL3 configuration uses 11 DMX channels.

It also supports automatic, sound-activated and master-slave modes for setups where a DMX controller is not required.

Does It Work on UAE Power?

Yes. The documented electrical input is AC110–240V, 50–60Hz, which includes the UAE's 220–240V / 50Hz mains supply.

The physical plug supplied with Stagify stock should still be confirmed before publication.

Is This Light Suitable for Outdoor Events?

The matching model is rated IP20, so it should be treated as an indoor stage-lighting fixture rather than a weatherproof outdoor light.

For outdoor events, it should only be used where the fixture is fully protected from rain, moisture and unsuitable environmental conditions.

Can It Be Used With a Fog or Haze Machine?

Yes. Fog or haze can make moving LED beams and laser effects more visible in the air.

Venue rules should be checked before using atmospheric effects, particularly where optical smoke-detection systems are installed.

Laser Use & Safety

This fixture contains red, green and blue lasers and should be positioned and operated by personnel familiar with professional stage-laser use.

Never direct laser output into audience areas, people's eyes, road traffic or aircraft. Public-event laser use in the UAE may require venue or authority approval depending on the installation and event.

The available documentation confirms the individual laser output powers but does not provide a verified laser-class designation for the Stagify stock unit, so I have intentionally not published a laser-class claim.

Order 3 Heads Moving Head Laser Lights in the UAE

Stagify supplies professional stage lighting and event-effect equipment across Dubai and the UAE for DJs, event companies, venues, AV installers and rental businesses.

The LED 3 Heads Moving Head Laser Stage Light can be integrated with DMX controllers, haze or fog effects, moving heads and other stage fixtures to create coordinated entertainment-lighting systems.

Contact Stagify for product compatibility, event-project requirements and bulk lighting enquiries.
